Product description：

Tabletop mounting structure, unique microphone appearance, mold design, aluminum metal cover and zinc alloy base are adopted. The overall fashion is generous, exquisite, firm and durable without paint falling. It is carved and processed by CNC Seiko. It adopts full band advanced sound head and high-quality host broadcast level full frequency microphone core to clearly capture the details of sound, fully improve the high fidelity and reduction of microphone sound, and improve the anti-interference of sound; High quality air pressure button, excellent feel.Optional meeting discussion and camera tracking functions. It is widely used in intelligent conference room, training room, lecture hall, command and control center, operation room, monitoring, multimedia remote video conference room and other occasions.

Product features：

1. Zinc alloy base with colored aluminum panel, the overall appearance is exquisite;

2. Professional high fidelity cardioid directional capacitive electret microphone with sensitive pickup and clear voice, and the bandwidth reaches 20Hz ~ 20kHz;

3. The anti-interference circuit design can prevent the interference of mobile phones and other electronic products;

4. The microphone pole and key are equipped with LED aperture, which can display the status of speaking and closing;

5. 3.3-inch LED screen with clear display content;

6. 8P-DIN special T-type cable is used for connection between units;

7. The chairman has the priority key to control the order of the meeting, which can close the speaking representative unit;

8. The microphone rod adopts gooseneck microphone rod with customized microphone core, which has excellent sound pickup effect;

9. Detachable microphone rod, optional formula shaped microphone rod.

10. The unit is passive equipment and powered by the system host

Product parameters:

Channel isolation:              > 85dB

Total harmonic distortion:        < 0.05%

Frequency response width:       20Hz ~ 20KHz

Dynamic range:                > 94db

Sensitivity:                   - 20dB

Signal to noise ratio:            > 96dba

Input impedance:              2K Ω

Maximum sound pressure level:   125dB (THD < 3%)

Equivalent noise:              20dBA (SPL)

Directivity:                   0 ° / 180 ° > 20dB (1kHz)

Display:                     2.3-inch LCD

Power supply:                Host - DC 24V

Installation method:           table type

Microphone:                 Panasonic microphone

Microphone tail line:          50cm

Mast length:                 42cm

Size:                       128 * 98 * 55mm (length, width and height)

Weight:                    0.75kg

Color:                      gray
